Anti-static TPEs

Anti-static TPEs

UV-resistant and Anti-static Solutions

Application fields: the wire and optical cables with the requirements of UV-resistant and anti-static to the sheathing materials and needing to pass the UL VW-1 test.Product features:

1. Excellent UV-resistant property, after irradiated for 168 hours in the QUV testing box, ΔE<1. The testing parameters are as follows:

Irradiance: 0.35W/m2; illumination: 4 hours illumination(UVA 340nm), 60℃ temperature; Condensation: 4 hours condensation, 50℃ temperature: The total time: 168 hours.

2. A long-term and stabilized anti-static property with the surface resistance reaching up to108Ω/square, and it can realize the matching of various kinds of colors;

3. The two properties above can either reach the standard simultaneously or be achieved respectively;

4. Mechanical property: in support of the wire to pass every item corresponding test of UL1581/758/62 and the non-migration test, standout elasticity;

5. Temperature resistant rate: in support of the wire to pass the UL 80℃/105℃ jacket test;

6. The flame rating: UL 94 V0 vertical burning, in full support of the wire to pass the UL VW-1 and CSA FT-4;

7. Appearance: comfortable and smooth, well-distributed exquisite; excellent wear-resistant property; providing glossy, semi-matte, and matte surface products for selection;

8. Excellent processing efficiency and property, not only just using PVC screw machine, it can realize the productive efficiency of forty to eighty meters per minute, but also appears very few imperfections in during processing such as salivation, particles, bumps, and pocking marks, etc.

Technical Data of Anti-static TPEs

Technical Data SheetModel

Material Properties
Test Standard
Test Condition
Unit
2590F-ESA-2451S
General Characteristics
Material Category
---
Appearance(Light/Semi-matte/Frosted)---
Extrusion/Injection
---
Physical CharacteristicsHardnessISO 4815SShore A86
ProportionISO 1183-g/cm³1.126
Melt IndexISO 1133-1:2011190℃/2.16kgg/10min0.1
Brittle TemperatureISO 812-
Mechanical Properties
ElongationISO37:2017200mm/min%436
Tensile StrengthISO37:2017200mm/minMpa10.26
Tearing StrengthISO34-1:2015500mm/minKN/m
Hot Air AgingElongation Retention RateISO37:2017-%
Tensile Strength Retention RateISO37:2017-%
Electrical Performance
Volume ResistivityASTM D257-Ohm-cm
PermittivityASTM D150--
Combustion PerformanceVertical Burning TestUL 943.0/6.0mm-
Oxygen IndexASTM D2863-%
Feature


Key Benefits of Anti-static TPEs

Key Benefits of Anti-static TPEs

· Competitive price      · Respond immediately      · Strong R&D capability      · Excellent after-sales service
