E Series High Elasticity TPEs
Applied Fields: High-end market TPEs wire & cable products with excellent comprehensive performances especially focus on elasticity and flexing properties.
Characteristics: Excellent comprehensive performances, especially recovery and tear strength, good surface smoothness.
Unique patent formula, PPS-free, can effectively prevent the stress cracking risk of TPEs sheath in long-term bending and winding applications;
| Technical Data Sheet | Model | ||||
| Material Properties | Test Standard | Test Condition | Unit | 2590F-ESS-1195S | |
| General Characteristics | Material Category | - | - | - | |
| Appearance(Light/Semi-matte/Frosted) | - | - | - | ||
| Extrusion/Injection | - | - | - | ||
| Physical Characteristics | Hardness | ISO 48 | 15S | Shore A | 88 |
| Proportion | ISO 1183 | - | g/cm³ | 0.942 | |
| Melt Index | ISO 1133-1:2011 | 190℃/2.16kg | g/10min | 1.2 | |
| Brittle Temperature | ISO 812 | - | ℃ | ||
| Mechanical Properties | Elongation | ISO37:2017 | 200mm/min | % | 450 |
| Tensile Strength | ISO37:2017 | 200mm/min | Mpa | 14.278 | |
| Tearing Strength | ISO34-1:2015 | 500mm/min | KN/m | ||
| Hot Air Aging | Elongation Retention Rate | ISO37:2017 | - | % | |
| Tensile Strength Retention Rate | ISO37:2017 | - | % | ||
| Electrical Performance | Volume Resistivity | ASTM D257 | - | Ohm-cm | |
| Permittivity | ASTM D150 | - | - | ||
| Combustion Performance | Vertical Burning Test | UL 94 | 3.0/6.0mm | - | |
| Oxygen Index | ASTM D2863 | - | % | ||
| Feature | |||||
