High Wear-resistance TPEs

High Wear-resistance TPEs

Fender-TTM TPU series (1090T series)

1. UL certified V0 grade polyether TPU:

UL94-V0 (1.5mm) flame retardant grade, fully support the conventional structural cable through the IEC60332-1-2 single vertical burning test;

2. High and low-temperature shrinkage rate, shrinkage rate ≤1% in high and low-temperature cycle test;

3. High security and reliability, support optic cable through various environmental tests and life tests:

Mold resistance

Authoritative certified mold-resistant materials: through the military standard mold resistance test (GJB150.10);

Hydrolysis resistance: Pass 1000/2000Hrs hydrolysis resistance test (different model) (85°C/85% RH, 1000/2000 Hrs);

High and low-temperature resistance: Wide temperature range for use, Pass 720Hrs high-temperature test (125°C, 720Hrs) and low-temperature destructive tests such as low-temperature winding (-50°C) and low-temperature shock (-50°C);

Acid and alkali resistant, oil resistant, chemical resistant: Pass various acid and alkali resistance, oil resistance and chemical resistance test (e.g: acid and alkali resistance: 23°C/168h, intensity change rate ≤ 30%, extended rate ≥100%; oil resistance: 70 °C / 24h oil resistance test, strength, and elongation, change rate ≤ 30%);

UV resistant: Pass UL1581 UV test (720Hrs UV cycle test, strength, and elongation, retention rate ≥ 80%);

4. High wear resistance: Polar material, high cohesive energy, and wear resistance are much better than conventional low-smoke halogen-free polyolefin materials (LSZH).

Technical Data of High Wear-resistance TPEs

Technical Data SheetModel

Material Properties
Test Standard
Test Condition
Unit2885F-ESU-1088S
General Characteristics
Material Category
---
Appearance(Light/Semi-matte/Frosted)---
Extrusion/Injection---
Physical CharacteristicsHardnessISO 4815SShore A85
ProportionISO 1183-g/cm³0.951
Melt IndexISO 1133-1:2011190℃/2.16kgg/10min3.2
Brittle TemperatureISO 812-
Mechanical Properties
ElongationISO37:2017200mm/min%475
Tensile StrengthISO37:2017200mm/minMpa14.5
Tearing StrengthISO34-1:2015500mm/minKN/m
Hot Air AgingElongation Retention RateISO37:2017-%
Tensile Strength Retention RateISO37:2017-%
Electrical Performance
Volume ResistivityASTM D257-Ohm-cm
PermittivityASTM D150--
Combustion PerformanceVertical Burning TestUL 943.0/6.0mm-
Oxygen IndexASTM D2863-%
Feature


Key Benefits of High Wear-resistance TPEs

Key Benefits of High Wear-resistance TPEs

· Competitive price      · Respond immediately      · Strong R&D capability      · Excellent after-sales service
