Super Soft TPEs

Super Soft TPEs

The rubber-like functional group is introduced into the material, and when applied to the cable sheath, it has more excellent wear resistance and soft and smooth rubber feel compared with the conventional TPEs cable sheath"

1. Authoritative certification: UL yellow card certification V0 TPEs material (yellow card number: E353106), can fully support conventional data lines pass UL758/1581 VW-1 combustion test;

2. Non-cracking: Unique patent formula, PPS-free (polyphenylene ether), can effectively prevent the stress cracking risk of TPEs sheath in long-term bending and winding applications;

3. Heat Resistance: Fully support the cable pass UL 758/1581 80℃/90℃/105℃ heat resistance test (113℃/121℃/136℃, 168Hrs)

4. More wear-resistant: the introduction of rubber functional groups provides better wear resistance and softer rubber touch compared to the conventional TPEs cable sheath;

5. Easy to process: High yield rate of extruding, achieve the processing efficiency of 80—200m/min. PVC equivalent screw.

6. High price-performance ratio: low specific gravity(≤1.07), high price-performance ratio, the ideal solution for conventional consuming electronic product sheath material."

Technical Data of Super Soft TPEs

Technical Data SheetModel

Material Properties
Test Standard
Test Condition
Unit
2560F-ESU-2514S
General Characteristics
Material Category
---
Appearance(Light/Semi-matte/Frosted)---
Extrusion/Injection
---
Physical CharacteristicsHardnessISO 4815SShore A55
ProportionISO 1183-g/cm³0.942
Melt IndexISO 1133-1:2011190℃/2.16kgg/10min0.7
Brittle TemperatureISO 812-
Mechanical Properties
ElongationISO37:2017200mm/min%423
Tensile StrengthISO37:2017200mm/minMpa5.25
Tearing StrengthISO34-1:2015500mm/minKN/m
Hot Air AgingElongation Retention RateISO37:2017-%
Tensile Strength Retention RateISO37:2017-%
Electrical Performance
Volume ResistivityASTM D257-Ohm-cm
PermittivityASTM D150--
Combustion PerformanceVertical Burning TestUL 943.0/6.0mm-
Oxygen IndexASTM D2863-%
Feature


Key Benefits of Super Soft TPEs

Key Benefits of Super Soft TPEs

· Competitive price      · Respond immediately      · Strong R&D capability      · Excellent after-sales service
